About this machine
About this technology
The CB Series of integrated filler/seamers provide canning technology designed specifically for and scaled to the needs of craft beverage packaging. Open air or atmospheric filling is cost-effective for still and lower-carbonation products, and is relatively simple to operate and maintain.
The accurate and repeatable fill level metering uses magnetic flow meter technology, with no moving parts. Because sanitation is critical, product contact parts, including CO2 pre-purge nozzles and product contact parts in individual fill valves are made from 316 stainless steel. Product supply piping and connections are all sanitary/hygienic, and of course, product supply is Clean In Place (CIP) capable, up to 180° with caustic cleaners.
Changeovers are fast and easy, thanks to quick change levers, and tooling adjustments are maintained between changeovers. Even the seaming cam is easy to remove and replace when you are changing material, can size and/or seaming specifications.
Contact us today to speak with one of our craft brew experts about the specific requirements of your project. We’re happy to assist you.
Product Details
- Integrated 12-head hygienic inline filler with dual-head seamer rated for continuous operation at speeds of up to 100 Containers Per Minute (CPM)
- Repeatable fill volume control using proprietary magnetic flowmeter technology capable of 1 ml precision input by operator on HMI, hygienic with no moving parts
- Sanitary/hygienic product supply piping and connections
- Discharge can rinser assembly with air dry
- Filler designed for easy change of can height and body diameter
- Sanitary 316 stainless steel CO2 pre-purge nozzles located directly behind filling heads limits the distance of travel from pre-purge to filling to only 1 can body diameter for all heads
- CO2 gassing tunnel between the filler discharge and lid application, featuring automatic shutoff to conserve CO2 usage, limits oxygen pickup between finished fill and lid application
- Under Cover Gassing (UCG) at lid applicator chute
- Cam optimized for beverage applications
- Easily removed/replaced for future changes in material, can size and/or seam specifications
- Easy-access hand wheel can height adjustment
- Differential pressure used to maintain level in product supply tank
- Engineered to maintain consistent pressure throughout entire fill cycle and production run
Technical Data
- Continuous operation at speeds of up to 100 Containers Per Minute (CPM)
- Variable speed range of 30-100 CPM
- Twelve filling heads
- Industry-leading controls with HMI includes intuitive interface featuring data logging screen for quality control
- HMI display includes live temperature, pressure and volume feedback
- Titanium nitride-coated Angelloy® seaming rolls with ceramic bearings
- Titanium nitride-coated Angelloy® seaming chucks
- Standard travel of can is from left to right
- Optimized for beverage can — height range 2.13” to 8.00”
- Product supply tank for tightly controlled pressure, producing consistent, quality fills
- Product supply tank and filler manifold connection on left
- Hardened tool steel seaming cam for long life
- Stainless steel product area and base assembly
